Share a mouse, keyboard, USB 5Gbps hub, and dual 4K 60Hz DisplayPort displays between two DisplayPort-enabled computers

This Dual-Monitor KVM Switch enables users to switch between two desktops that are USB-A and DisplayPort enabled. It allows for sharing of dual-4K 60Hz DisplayPort monitors, a keyboard and mouse, and two USB 5Gbps devices.

Fast Switching with USB Emulation

USB Emulation technology enables faster switching of a keyboard, video, and mouse compared to traditional KVMs. USB Emulation also ensures compatibility with combination keyboards/mice as well as keyboards featuring additional function keys.

Dual-4K 60Hz Displays & USB 5Gbps Hub Ports

This TAA-Compliant KVM Switch supports dual-4K 60Hz DisplayPort monitors, making it ideal for working with high-resolution graphics or video. Additionally, it offers two USB 3.2 Gen 1 (5Gbps) Hub Ports for fast data transfer, and two USB 2.0 HID Ports for the keyboard and mouse. 8kV air and 6kV contact Electrostatic Discharge (ESD) protection.

Customizable Switching

This Universal KVM Switch provides various switching options, including hotkey or push-button switching. Hotkeys allow for independent switching of USB/Video and Audio, enabling audio playback from one computer while controlling the other. An audible buzzer confirms hotkey input, and LEDs provide a visual status of the selected host.

Enhance Productivity and Device Management with the StarTech.com Connectivity Tools Application

Developed to improve performance and security, StarTech.com Connectivity Tools is the only software suite on the market that works with a wide range of IT connectivity accessories. The software suite includes:

• Advanced Windows Layout Utility: Setup and save custom windows layouts.
• MAC Address Pass-Through Utility: Improve network security.
• USB Event Monitoring Utility: Track and log connected USB devices.
• Wi-Fi Auto Switch Utility: Enable users to quickly access faster network speeds via wired LAN.

For more information and to download the StarTech.com Connectivity Tools application, please visit: www.startech.com/connectivity-tools

The StarTech.com Advantage


StarTech.com P2DD46A2-KVM-SWITCH. Keyboard port type: USB, Mouse port type: USB, Video port type: DisplayPort. HD type: 4K Ultra HD, Maximum resolution: 3840 x 2160 pixels, Data transfer rate (max): 5 Gbit/s. Product color: Black, Maximum cable length: 295.3" (7.5 m), Mean time between failures (MTBF): 173052 h. Power source: DC, Input voltage: 100 - 240 V, Input current: 1 A. Compliance certificates: RoHS

Number of computers controlled	2
Keyboard port type	USB
Mouse port type	USB
Video port type	DisplayPort
Console ports	3.5mm headphone, 3.5mm mic, DisplayPort, USB A
DisplayPorts quantity	4
DisplayPort version	1.2
Console USB ports quantity	4
Console DisplayPorts ports quantity	2
Audio connections	Yes
Headphone outputs	3
Number of microphone inputs	3
DC-in jack	Yes
HD type	4K Ultra HD
Maximum resolution	3840 x 2160 pixels
Data transfer rate (max)	5 Gbit/s
Scan interval	10,20,30,40,50,60 s
Plug and Play	Yes
Daisy chain	No
Rack mounting	No
Product color	Black
Maximum cable length	295.3" (7.5 m)
LED indicators	Yes
Push button	Yes
Hot keys	Yes
Mean time between failures (MTBF)	173052 h
Built-in display	No
On Screen Display (OSD)	No
Power source	DC
Input voltage	100 - 240 V
Input current	1 A
Output voltage	12 V
Output current	3 A
Compatible power plug types	EU, JP, UK, US
Compliance certificates	RoHS
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 90%
Width	3.94" (100 mm)
Depth	6.42" (163 mm)
Height	2.6" (66 mm)
Weight	28.2 oz (800 g)
Package width	6.3" (160 mm)
Package depth	10.6" (270 mm)
Package height	7.56" (192 mm)
Package weight	2.87 lbs (1.3 kg)
Quick installation guide	Yes
Master (outer) case width	21.8" (554 mm)
Master (outer) case length	19.5" (495 mm)
Master (outer) case height	8.39" (213 mm)
Quantity per master (outer) case	6 pc(s)
Sustainability compliance	Yes
IP control	No
