The Fast Ethernet PoE+ Extender TL-POE10E extends a PoE/PoE+ network connection an additional 100m – 250m (10 Mbps Mode) from the PoE power source equipment. TL-POE10E expands network deployment with 802.3af/at PoE compliant devices, making it ideal for remote cabling requirements in surveillance scenarios. Distance will no longer be a barrier to network deployment.


TP-Link Omada TL-POE10E. Type: Network repeater, Maximum transfer distance: 9842.5" (250 m), Data transfer rate: 100 Mbit/s. Cabling technology: 10/100Base-T(X), Networking standards: IEEE 802.3i, IEEE 802.3u. Host interface: RJ-45. Product color: Black, Housing material: Plastic, LED indicators: Power. Width: 2.8" (71 mm), Depth: 1.02" (26 mm), Height: 0.63" (16 mm)

Type	Network repeater
Maximum transfer distance	9842.5" (250 m)
Data transfer rate	100 Mbit/s
Cable types supported	Cat5e
Ethernet LAN data rates	10,100 Mbit/s
Auto-negotiation	Yes
Plug and Play	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3i, IEEE 802.3u
Host interface	RJ-45
Ethernet LAN (RJ-45) ports	2
Power over Ethernet (PoE) ports quantity	2
RJ-45 input ports	1
RJ-45 output ports	1
Product color	Black
Housing material	Plastic
LED indicators	Power
Quantity per pack	1 pc(s)
Certification	FCC, CE, RoHS
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Width	2.8" (71 mm)
Depth	1.02" (26 mm)
Height	0.63" (16 mm)
Quick start guide	Yes
Compliance certificates	Federal Communications Commission (FCC), RoHS
Sustainability compliance	Yes
