The TL-SF1005D 5-Port 10/100Mbps desktop switch provides an easy way to expand your wired network. All 5 ports support auto-MDI/MDIX, eliminating the need to worry about the type of cable to use. Featuring full duplex mode, the TL-SF1005D can process data at a rate of up to 200Mbps making it an ideal choice for expanding your high performance wired network. Moreover, with innovative energy-efficient technology, the TL-SF1005D can save power consumption, making it an eco-friendly solution for your home or office network.

High Performance
TL-SF1005D Fast Ethernet Switch provides 5 10/100Mbps Auto-Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports..Featuring non-blocking switching architecture,TL-SF1005D forwards and filters packets at full wire-speed for maximum throughput. With 2K Jumbo frame, the performance of large files transfers is improved significantly. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the traffic congestion and make TL-SF1005D work reliably.

TP-Link TL-SF1005D. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 5. Full duplex. MAC address table: 1000 entries, Switching capacity: 1.6 Gbit/s. Networking standards: IEEE 802.3u, IEEE 802.3x. DC input voltage: 5 V. Power connector: DC-in jack

Switch type	Managed
Quality of Service (QoS) support	Yes
Web-based management	Yes
Basic switching RJ-45 Ethernet ports quantity	5
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
Fast Ethernet (copper) ports quantity	5
Power connector	DC-in jack
Networking standards	IEEE 802.3u, IEEE 802.3x
10G support	No
Copper ethernet cabling technology	10BASE-T, 100BASE-T
Full duplex	Yes
Flow control support	Yes
Auto MDI/MDI-X	Yes
Spanning tree protocol	Yes
Ethernet LAN data rates	10,100 Mbit/s
Auto-negotiation	Yes
MAC address table	1000 entries
Switching capacity	1.6 Gbit/s
Store-and-forward	Yes
Supported network protocols	CSMA/CD, TCP/IP
Rack mounting	No
Product color	White
LED indicators	Yes
Fanless	Yes
Power source	DC
Power supply included	No
AC input voltage	220 V
AC input frequency	50 Hz
DC input voltage	5 V
Input current	0.6 A
Power consumption (typical)	1.87 W
Power consumption (max)	1.87 W
Power over Ethernet (PoE)	No
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Heat dissipation	6.38 BTU/h
Width	4.07" (103.5 mm)
Depth	2.76" (70 mm)
Height	0.866" (22 mm)
Cables included	AC
User guide	Yes
AC adapter included	Yes
Package type	Box
Package width	3.58" (91 mm)
Package depth	4.25" (108 mm)
Package height	3.35" (85 mm)
Package weight	6.7 oz (190 g)
Compliance certificates	CE, Federal Communications Commission (FCC), RoHS
Certification	FCC, RoHs
Sustainability compliance	Yes
