Ecopower II is the next generation of Ecopower TOOQ power supply. The new Power Supplies version includes high quality Active PFC (Active PFC, PF> 0.99, not all models have Altive PFC), which guarantees at least 78% efficiency. With Active PFC technology, the power supply produces much less heat than another with Passive PFC, which can prolong the power supply life. In addition, the Ecopower II series has a super quiet high quality fan, very stable dual +12V rail and high-tech electronic protection system.

TooQ Fonte Ecopower II. Total power: 500 W, AC input frequency: 50 - 60 Hz, Power Good signal delay range: 100 - 500 ms. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 13" (33 cm), SATA power cable length: 480 mm. Purpose: PC, Power supply unit (PSU) form factor: SFX, Supported motherboard form factors: micro ATX. Product color: Silver, Fan diameter: 3.15" (8 cm), Number of fans: 1 fan(s). Compliance certificates: RoHS, Certification: CE

Total power	500 W
AC input frequency	50 - 60 Hz
Power Good signal delay range	100 - 500 ms
Power protection features	Over current, Over voltage, Overheating, Overload, Short circuit, Under voltage
Motherboard power connector	20+4 pin ATX
Peripheral (Molex) power connectors (4-pin)	0
Motherboard power cable length	13" (33 cm)
Number of SATA power connectors	2
SATA power cable length	480 mm
CPU power connector (4+4 pin)	Yes
CPU power cable length	16.9" (43 cm)
ATX power connector (20+4 pin)	Yes
Cabling type	Non-Modular
Purpose	PC
Power supply unit (PSU) form factor	SFX
Supported motherboard form factors	micro ATX
ATX version	1.3
Noise level	20 dB
Mean time between failures (MTBF)	10000 h
Product color	Silver
Fan diameter	3.15" (8 cm)
Number of fans	1 fan(s)
On/off switch	Yes
Operating temperature (T-T)	0 - 40 °C
Compliance certificates	RoHS
Certification	CE
Width	2.5" (63.5 mm)
Depth	4.92" (125 mm)
Height	3.94" (100 mm)
Manual	Yes
Package width	3.15" (80 mm)
Package depth	7.76" (197 mm)
Package height	6.5" (165 mm)
Package weight	34.4 oz (975 g)
Package type	Box
Number of cartons per pallet	360 pc(s)
Master (outer) case volume	48848 cm³
Quantity per master (outer) case	20 pc(s)
Package volume	2442.4 cm³
