The DAP-2680 Wireless AC1750 Wave 2 Dual-Band PoE Access Point is designed to support small to medium business or enterprise environments by providing network administrators with secure and manageable dual-band wireless LAN options, and utilising the cutting-edge speed of 802.11ac Wave 2.
The DAP-2680 delivers maximum combined wireless signal rates of up to 1750 Mbps and supports MU-MIMO technology that allows multiple devices to get high-bandwidth Wi-Fi signal at the same time, distributing data more efficiently. To maximise total return on investment, the DAP-2680 can be configured to optimise network performance based on any one of its multiple operation modes.
For centralised network management, administrators can use D-Link’s free Nuclias Connect
software or Nuclias Connect Hub (DNH-100)5 to configure and manage multiple access points.
In addition to streamlining the management process, Nuclias Connect provides network
administrators with the means to verify and conduct regular maintenance checks remotely,
eliminating the need to send personnel out to physically verify proper operation.

Enjoy High-Performance Wireless Connectivity
Harness the power of IEEE 802.11ac Wave 2 wireless and experience wireless speeds of up to 1750 Mbps, perfect for high-demand business applications

MU-MIMO with Beamforming
Dramatically improves the wireless range and performance as well as allowing multiple devices to
connect simultaneously to the wireless network

Scalable, Flexible, Centralised AP Management
Centrally manage up to 1000 APs with Nuclias Connect, complete with a multi-tenant structure that
provides multi-layer management authority

D-Link DAP-2680. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1750 Mbit/s. Security algorithms: 64-bit WEP, 128-bit WEP, SNMP, SNMPv3, SSH, SSID, SSL/TLS, WPA, WPA-Enterprise, WPA2,.... Power over Ethernet (PoE). Product color: White

2.4 GHz	Yes
5 GHz	Yes
6 GHz	No
Maximum data transfer rate	1750 Mbit/s
Frequency band	2.4 - 2.4835; 5.15 - 5.35; 5.47 - 5.85 GHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u
Transmitting power	26.5 dBmW
Security algorithms	64-bit WEP, 128-bit WEP, SNMP, SNMPv3, SSH, SSID, SSL/TLS, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise
MAC address filtering	Yes
Web-based management	Yes
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	0
Power over Ethernet (PoE)	Yes
Output voltage	12 V
Output current	2 A
Placement	Table, Wall
Product color	White
LED indicators	Power, Status
Internal	No
Antennas quantity	3
Antenna gain level (max)	4.2 dBi
Shipping (inner) case length	23.6" (59.9 cm)
Shipping (inner) case width	11.5" (29.3 cm)
Shipping (inner) case height	9.45" (24 cm)
Shipping (inner) case net weight	7.58 lbs (3.44 kg)
Quantity per shipping (inner) case	5 pc(s)
Pallet gross weight (air)	686.5 lbs (311.4 kg)
Number of cartons per pallet (air)	48 pc(s)
Quantity per pallet (air)	240 pc(s)
Pallet length	43.3" (110 cm)
Pallet width	47.2" (120 cm)
Pallet height (air)	81.1" (2.06 m)
Pallet gross weight (sea)	686.5 lbs (311.4 kg)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per pallet (sea)	240 pc(s)
Pallet height (sea)	81.1" (2.06 m)
Shipping (inner) case weight	13.3 lbs (6.05 kg)
Certification	FCC, UL, CE, FCC, UL
Width	7.48" (190 mm)
Depth	7.48" (190 mm)
Height	1.76" (44.8 mm)
Weight	20.5 oz (580 g)
Package width	8.07" (205 mm)
Package depth	10.6" (270 mm)
Package height	4.41" (112 mm)
Package weight	2.38 lbs (1.08 kg)
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 65 °C
Storage relative humidity (H-H)	5 - 95%
Harmonized System (HS) code	85176990
