Switch type | Unmanaged |
Basic switching RJ-45 Ethernet ports quantity | 9 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Installed SFP modules quantity | 0 |
Installed SFP+ modules quantity | 0 |
Combo SFP ports quantity | 1 |
Networking standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
10G support | No |
Copper ethernet cabling technology | 10BASE-T, 100BASE-TX |
Cable types supported | Cat3, Cat4, Cat5, Cat5e |
Flow control support | Yes |
Auto MDI/MDI-X | Yes |
Auto-negotiation | Yes |
MAC address auto-learning supported | Yes |
MAC address auto-aging supported | Yes |
MAC address table | 4000 entries |
Switching capacity | 20 Gbit/s |
Store-and-forward | Yes |
Packet buffer memory | 14.88 MB |
Rack mounting | No |
Product color | Black |
LED indicators | Yes |
Fanless | Yes |
Power source | DC |
Input current | 2.43 A |
Input voltage | 53.5 V |
Power consumption (max) | 141.4 W |
Power over Ethernet (PoE) | Yes |
Power over Ethernet plus (PoE+) ports quantity | 8 |
Power over Ethernet (PoE) power per port | 30 W |
Total Power over Ethernet (PoE) budget | 123 W |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -40 - 70 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 90% |
Heat dissipation | 482.17 BTU/h |
Width | 8.23" (209 mm) |
Depth | 4.96" (126 mm) |
Height | 1.02" (26 mm) |
Quick start guide | Yes |
Package width | 9.45" (240 mm) |
Package depth | 12.4" (315 mm) |
Package height | 2.76" (70 mm) |
Package weight | 3.11 lbs (1.41 kg) |
Certification | CE, FCC |
Harmonized System (HS) code | 85176990 |
