Switch type | Unmanaged |
Quality of Service (QoS) support | Yes |
Basic switching RJ-45 Ethernet ports quantity | 16 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Gigabit Ethernet (copper) ports quantity | 16 |
Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
Cable types supported | Cat3, Cat4, Cat5, Cat5e, Cat6 |
Port mirroring | Yes |
Full duplex | Yes |
Flow control support | Yes |
Link aggregation | Yes |
Broadcast storm control | Yes |
Rate limiting | Yes |
Auto MDI/MDI-X | Yes |
Auto-negotiation | Yes |
Cable length detection | Yes |
VLAN support | Yes |
Virtual LAN features | Protocol-based VLAN, Tagged VLAN |
Number of VLANs | 32 |
MAC address table | 8000 entries |
Switching capacity | 32 Gbit/s |
Forwarding rate | 23.81 Mpps |
Store-and-forward | Yes |
Number of queues | 4 |
Jumbo frames support | Yes |
Jumbo frames | 9000 |
Packet buffer memory | 4.1 MB |
IGMP snooping | Yes |
Loop protection | Yes |
Stackable | Yes |
Product color | Black |
Housing material | Metal |
LED indicators | Yes |
Wall mountable | Yes |
Power supply included | Yes |
AC input voltage | 220 V |
AC input frequency | 50 Hz |
DC input voltage | 9 V |
Input current | 0.6 A |
Power consumption (typical) | 11.72 W |
Power consumption (max) | 144.28 W |
Power over Ethernet (PoE) | Yes |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -40 - 70 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 90% |
Heat dissipation | 490.55 BTU/h |
Width | 11.3" (286 mm) |
Depth | 4.4" (111.7 mm) |
Height | 1" (25.4 mm) |
Quick start guide | Yes |
Package width | 8.94" (227 mm) |
Package depth | 17.1" (434 mm) |
Package height | 2.76" (70 mm) |
Package weight | 4.41 lbs (2 kg) |
