Intel Core Ultra 5 245K. Processor family: Intel Ultra 5 core, processor socket: LGA 1851 (socket V1), processor manufacturer: Intel. Neural processor unit (NPU): Intel Ai Boosts, Software Frameworks supported by NPU: DirectML, Openvino, Windows ML, Onnx RT, Webnn, Total processor performance up to: 30 tops. Memory channels: Dual-channel, maximum internal memory supported by the processor: 192 GB, memory types supported by the processor: DDR5-SDRAM. Integrated graphics card template: Intel Graphics, supported outputs of the integrated graphics card adapter: DisplayPort 2.1, Embedded DisplayPort (EDP) 1.4B, HDMI 2.1, Basic frequency of the integrated graphics card adapter: 300 MHz. Market segment: Desktops, Terms of Use: Workstation, PC / Client / Tablet, Version of PCI Express Slots: 4.0, 5.0

Processor family	Intel Ultra 5 core
Processor core number	14
Processor socket	LGA 1851 (socket v1)
Box	Yup
Cooler included	No
Processor manufacturer	Intel
Processor model	245k
Processor operating mode	64-bit
Processor generation	Intel Core Ultra (Series 2)
Heart of performance	6
Efficient nuclei	8
Maximum frequency of the Turbo processor	5.2 GHz
Frequency of increase in core performance	5.2 GHz
Basic performance core frequency	4.2 GHz
Frequency of efficient core enhancement	4.6 GHz
Efficient core base frequency	3.6 GHz
Processor cache	24 MB
Type of processor cache	Smart cache
Basic processor power	125 W
Maximum turbo power	159 W
Framework artificial intelligence software supported by the CPU	DirectML, Openvino, Windows ML, Onnx RT, Webnn
Step	B0
Maximum number of DMI lanes	8
Processor code name	Lake Arrow
ARK processor ID	241067
Neural processing unit (NPU)	Intel Ai boost
Sparse support	Yup
Support of Windows Studio effects	Yup
Framework software to supported by NPU	DirectML, Openvino, Windows ML, Onnx RT, Webnn
Total processor performance up to	30 Tops
NPU performance up to	13 Tops
GPU performance up to	8 Tops
Memory channels	Dual-channel
Maximum internal memory supported by the processor	192 GB
Types of memory supported by the processor	Ddr5-SDRAM
Clock memory speed supported by the processor	6400 MHz
Data integrity control	Yup
Integrated graphics card	Yup
Separate graphics card adapter	No
Integrated graphics card template	Intel Graphics
Dedicated graphics card	Unavailable
Outputs supported by the integrated graphics card adapter	DisplayPort 2.1, Built-in DisplayPort (EDP) 1.4B, HDMI 2.1
Basic frequency of the integrated graphics card adapter	300 MHz
Integrated graphics card adapter dynamic frequency (maximum)	1900 MHz
Number of views (Integrated graphics card)	4
DirectX version of the integrated graphics card adapter	12.0
OpenGL version of the integrated graphics card adapter	4.5
Refreshment frequency of the integrated graphic adapter at maximum resolution (DisplayPort)	60 Hz
Refreshment frequency of the integrated graphic adapter at maximum resolution (EDP - integrated flat panel)	60 Hz
Refreshment frequency of the graphic adapter integrated at maximum resolution (HDMI)	60 Hz
Installed graphics card adapter ID	0x7d67
Xe-cores	4
Execution disabling bits	Yup
Inactive states	Yup
Thermal monitoring technology	Yup
Market segment	Desk
Terms of use	Workstation, PC / Client / Tablet
Maximum number of PCI Express lanes	24
PCI Express slot version	4.0, 5.0
Supported instructions	AVX 2.0, SSE4.1, SSE4.2
Scalability	1s
Built-in options available	No
Description of the thermal solution	PCG 2020A
DMI review (Direct Media Interface)	4.0
Classification number of export control (eccn)	5a992c
Automatic tracking system of the goods classification (CCATS)	740.17b1
Technology Intel® Turbo Boost	2.0
Quick Sync Video Inteltecnology Technology	Yup
Intel® New Instructions AESINTEL® AES-NI	Yup
Enhanced technology Intel Speedstep	Yup
Reliable intelet technology	Yup
Technology Intel® speed change	Yup
Intel® Thunderbolt 4	Yup
Inteltecnology of execution flow control (CET)	Yup
Intel Thread manager	Yup
Intel® VT-X with extended pages tables (EPT)	Yup
Intel® secure key	Yup
Active intelestion technology (Intel® AMT)	Yup
Intel® OS Guard	Yup
Intel® 64	Yup
Technology Intel® Virtualization (VT-X)	Yup
Virtualization intellitecnology for direct I / O (VT-D)	Yup
Intel® Boot Guard	Yup
Intel® Deep Learning Boost (Intel® DL Boost) on the CPU	Yup
Axil volume management (VMD)	Yup
Running control based on modes (MBE)	Yup
Technology Intel® Standard manageability (ISM)	Yup
Intel® Recovery with one click	Yup
Intel® Stable IT platform program (SIPP)	Yup
Intel® Remote platform cancellation (RPE)	Yup
Intelvirgualization technology with redirection protection (VT-RP)	Yup
Intel® Deep Learning Boost (Intel® DL Boost) on GPU	Yup
Suitability of the corporate platform Intel vpro®	Yup
Threat detection technology Intel® (TDT)	Yup
Fitness Intel® Hardware shield	Yup
Technology Intel® Total memory encryption - Multi key	Yup
Maximum operating temperature	105 ° C
OpenLC version	3.0
Harmonized system code (SA)	8542310050
Cache L2	26624 KB
Supported maximum RAM	192 GB
Launch date	Q4'24
State	Launched
Memory speed (max)	6400 MHz
Graphic output	DP2.1 UHBR20, HDM2.1 FRL 12GHz, EDP1.4B
