Intel Core Ultra 5 245kf. Processor family: Intel Ultra 5 core, processor socket: LGA 1851 (socket V1), processor manufacturer: Intel. Neural processor unit (NPU): Intel Ai Boosts, Framework software supported by the NPU: DirectML, Openvino, Windows ML, Onnx RT, Webnn, Total processor performance up to: 22 Tops. Memory channels: dual-channel, maximum internal memory supported by the processor: 192 GB, memory types supported by the processor: DDR5-SDRAM. Market segment: Desktop, Terms of Use: PC / Client / Tablet, version of PCI Express slots: 4.0., 5.0. Cache L2: 26624 KB, maximum supported RAM: 192 GB

Processor family	Intel Ultra 5 core
Processor core number	14
Processor socket	LGA 1851 (socket v1)
Box	No
Cooler included	No
Processor manufacturer	Intel
Processor model	245kf
Processor operating mode	64-bit
Processor generation	Intel Core Ultra (Series 2)
Heart of performance	6
Efficient nuclei	8
Maximum frequency of the Turbo processor	5.2 GHz
Frequency of increase in core performance	5.2 GHz
Basic performance core frequency	4.2 GHz
Frequency of efficient core enhancement	4.6 GHz
Efficient core base frequency	3.6 GHz
Processor cache	24 MB
Type of processor cache	Smart cache
Basic processor power	125 W
Maximum turbo power	159 W
Framework artificial intelligence software supported by the CPU	DirectML, Openvino, Windows ML, Onnx RT, Webnn
Step	B0
Maximum number of DMI lanes	8
Processor code name	Lake Arrow
ARK processor ID	241066
Neural processing unit (NPU)	Intel Ai boost
Sparse support	Yup
Support of Windows Studio effects	Yup
Framework software to supported by NPU	DirectML, Openvino, Windows ML, Onnx RT, Webnn
Total processor performance up to	22 Tops
NPU performance up to	13 Tops
Memory channels	Dual-channel
Maximum internal memory supported by the processor	192 GB
Types of memory supported by the processor	Ddr5-SDRAM
Clock memory speed supported by the processor	6400 MHz
Integrated graphics card	No
Separate graphics card adapter	No
Integrated graphics card template	Unavailable
Dedicated graphics card	Unavailable
Execution disabling bits	Yup
Inactive states	Yup
Thermal monitoring technology	Yup
Market segment	Desk
Terms of use	PC / client / tablet
Maximum number of PCI Express lanes	24
PCI Express slot version	4.0, 5.0
Supported instructions	AVX 2.0, SSE4.1, SSE4.2
Scalability	1s
Built-in options available	No
Description of the thermal solution	PCG 2020A
DMI review (Direct Media Interface)	4.0
Classification number of export control (eccn)	5a992c
Automatic tracking system of the goods classification (CCATS)	740.17b1
Technology Intel® Turbo Boost	2.0
Intel® New Instructions AESINTEL® AES-NI	Yup
Enhanced technology Intel Speedstep	Yup
Reliable intelet technology	Yup
Technology Intel® speed change	Yup
Intel® Thunderbolt 4	Yup
Inteltecnology of execution flow control (CET)	Yup
Intel Thread manager	Yup
Intel® VT-X with extended pages tables (EPT)	Yup
Intel® secure key	Yup
Intel® OS Guard	Yup
Intel® 64	Yup
Technology Intel® Virtualization (VT-X)	Yup
Virtualization intellitecnology for direct I / O (VT-D)	Yup
Intel® Boot Guard	Yup
Intel® Deep Learning Boost (Intel® DL Boost) on the CPU	Yup
Axil volume management (VMD)	Yup
Running control based on modes (MBE)	Yup
Technology Intel® Standard manageability (ISM)	Yup
Maximum operating temperature	105 ° C
Harmonized system code (SA)	8542310050
Cache L2	26624 KB
Supported maximum RAM	192 GB
Launch date	Q4'24
State	Launched
Memory speed (max)	6400 MHz
