Intel Core i9-14900K. Processor family: Intel® Core ™ i9, Processor socket: LGA 1700, processor manufacturer: Intel. Memory channels: dual-channel, maximum internal memory supported by the processor: 192 GB, memory types supported by the processor: DDR4-SDRAM, DDR5-SDRAM. Integrated graphics card template: Intel UHD Graphics 770, outputs supported by the integrated graphics card adapter: Embedded DisplayPort (EDP) 1.4B, DisplayPort 1.4a, HDMI 2.1, Basic frequency of the integrated graphics card adapter: 300 MHz. Market segment: Desktop, Terms of use: Workstation, PC / Client / Tablet, version of PCI Express slots: 4.0, 5.0. Intel® Frequency of Turbo Boost Technology Max 3.0: 5.8 GHz., Intel® Thermal speed increase frequency: 6 GHz

Processor family	Intel® Core ™ i9
Processor core number	24
Processor socket	LGA 1700
Box	Yup
Cooler included	No
Processor manufacturer	Intel
Processor model	i9-14900k
Processor operating mode	64-bit
Processor generation	Intel Core i9-14xxx
Number of processor threads	32
Heart of performance	8
Efficient nuclei	16
Maximum frequency of the Turbo processor	6 GHz
Frequency of increase in core performance	5.6 GHz
Basic performance core frequency	3.2 GHz
Frequency of efficient core enhancement	4.4 GHz
Efficient core base frequency	2.4 GHz
Processor cache	36 MB
Type of processor cache	Smart cache
Basic processor power	125 W
Maximum turbo power	253 W
Step	B0
Maximum number of DMI lanes	8
Memory band supported by the processor (maximum)	89.6 GB / s
Processor code name	Raptor Lake
ARK processor ID	236773
Memory channels	Dual-channel
Maximum internal memory supported by the processor	192 GB
Types of memory supported by the processor	DDR4-SDRAM, DDR5-SDRAM
Data integrity control	Yup
Non-etc.	Yup
Memory bandwidth (maximum)	89.6 GB / s
Integrated graphics card	Yup
Separate graphics card adapter	No
Integrated graphics card template	Intel UHD Graphics 770
Dedicated graphics card	Unavailable
Outputs supported by the integrated graphics card adapter	Embedded DisplayPort (EDP) 1.4B, DisplayPort 1.4a, HDMI 2.1
Basic frequency of the integrated graphics card adapter	300 MHz
Integrated graphics card adapter dynamic frequency (maximum)	1650 MHz
Number of views (Integrated graphics card)	4
DirectX version of the integrated graphics card adapter	12.0
OpenGL version of the integrated graphics card adapter	4.5
Maximum resolution of the integrated graphics card adapter (DisplayPort)	7680 x 4320 pixels
Maximum resolution of the integrated graphic adapter (EDP - integrated flat panel)	5120 x 3200 pixels
Maximum resolution of the integrated graphics card adapter (HDMI)	4096 x 2160 pixels
Refreshment frequency of the integrated graphic adapter at maximum resolution (DisplayPort)	60 Hz
Refreshment frequency of the integrated graphic adapter at maximum resolution (EDP - integrated flat panel)	120 Hz
Refreshment frequency of the graphic adapter integrated at maximum resolution (HDMI)	60 Hz
Installed graphics card adapter ID	0xa780
Number of operating units	32
Multi-format codec motors	2
Execution disabling bits	Yup
Inactive states	Yup
Thermal monitoring technology	Yup
Market segment	Desk
Terms of use	Workstation, PC / Client / Tablet
Maximum number of PCI Express lanes	20
PCI Express slot version	4.0, 5.0
PCI Express configuration	1x16 + 1x4, 2x8 + 1x4
Supported instructions	AVX 2.0, SSE4.1, SSE4.2
Scalability	1s
CPU configuration (max)	1
Built-in options available	No
Description of the thermal solution	PCG 2020A
DMI review (Direct Media Interface)	4.0
Classification number of export control (eccn)	5a992c
Automatic tracking system of the goods classification (CCATS)	740.17b1
Intelil text is not provided. Please provide the text you want to translate. Hyper Threading technology)Intel® HT technology	Yup
Technology Intel® Turbo Boost	2.0
Quick Sync Video Inteltecnology Technology	Yup
Ligal HD video intelleclanology (Intel® CVT HD)	Yup
Intel® New Instructions AESINTEL® AES-NI	Yup
Enhanced technology Intel Speedstep	Yup
Technology Intel® speed change	Yup
Increased Thermal Speed Intelsorry, I CAN'T Translate This as It's Not A Spanish Text. It's Just a Symbol.	Yup
Technology Intel®Adaptive Boost	Yup
Intel® Frequency of Turbo Boost Max 3.0 technology	5.8 GHz
Intel® Gaussian accelerator and NeuralIntel® GNA) 3.0	Yup
Intel® Frequency of increased thermal speed	6 GHz
Inteltecnology of execution flow control (CET)	Yup
Intel Thread manager	Yup
Intel® VT-X with extended pages tables (EPT)	Yup
Intel® secure key	Yup
Intel® OS Guard	Yup
Intel® 64	Yup
Technology Intel® Virtualization (VT-X)	Yup
Virtualization intellitecnology for direct I / O (VT-D)	Yup
Technology Intel Turbo Boost max 3.0	Yup
Intel® Boot Guard	Yup
Intel® Deep Learning Boost (Intel® DL Boost) on the CPU	Yup
Axil volume management (VMD)	Yup
Running control based on modes (MBE)	Yup
Technology Intel® Standard manageability (ISM)	Yup
T-intersection	100 ° C
OpenLC version	3.0
Harmonized system code (SA)	8542310001
Size of the processor package	45 x 37.5 mm
Cache L2	32768 KB
Supported maximum RAM	192 GB
Launch date	Q4'23
State	Launched
Graphic output	EDP 1.4B, DP 1.4a, HDMI 2.1
