Intel Xeon E-2336. Processor family: Intel XEON E, Processor socket: LGA 1200 (socket H5), processor lithograph: 14 Nm. Memory channels: dual-channel, maximum internal memory supported by the processor: 128 GB, memory types supported by the processor: DDR4-SDRAM. Market segment: Server, Terms of Use: Server / Enterprise, PCI Express Configuration: 1x16 + 1x4, 2x8 + 1x4, 1x8 + 3x4. Intel® Turbo Frequency Boost Technology 2.0: 4.8 GHz, support for the maximum enclave size for Intelsgx: 0.5 GB. Type of package: box for retail

Processor family	Intel Xeon e
Processor core number	6
Processor socket	LGA 1200 (socket H5)
Lithograph processor	14 Nm
Box	Yup
Cooler included	No
Processor manufacturer	Intel
Processor model	And-2336
Basic processor frequency	2.9 GHz
Processor operating mode	64-bit
Component for	Server / Workstation
Number of processor threads	12
System bus	8 GT / s
Maximum frequency of the Turbo processor	4.8 GHz
Processor cache	12 MB
Type of processor cache	Smart cache
Project thermal power (TDP)	65 W
ARK processor ID	212253
Memory channels	Dual-channel
Maximum internal memory supported by the processor	128 GB
Types of memory supported by the processor	Ddr4-SDRAM
Data integrity control	Yup
Integrated graphics card	No
Separate graphics card adapter	No
Integrated graphics card template	Unavailable
Dedicated graphics card	Unavailable
Execution disabling bits	Yup
Inactive states	Yup
Thermal monitoring technology	Yup
Market segment	Server
Terms of use	Server / company
Maximum number of PCI Express lanes	20
PCI Express slot version	4.0
PCI Express configuration	1x16 + 1x4, 2x8 + 1x4, 1x8 + 3x4
Supported instructions	SSE4.1, SSE4.2, AVX 2.0, AVX-512
Scalability	1s
CPU configuration (max)	1
Built-in options available	No
Classification number of export control (eccn)	5a992cn3
Automatic tracking system of the goods classification (CCATS)	G167599
Intelil text is not provided. Please provide the text you want to translate. Hyper Threading technology)Intel® HT technology	Yup
Technology Intel® Turbo Boost	2.0
Intel® New Instructions AESINTEL® AES-NI	Yup
Enhanced technology Intel Speedstep	Yup
Reliable intelet technology	Yup
Intel® Memory Protection Extensions Members MPX)	Yup
Intel® Frequency of Turbo Boost 2.0 technology	4.8 GHz
Transactional synchronization intensity	No
Support for the maximum enclave size Intel® SGX	0.5 GB
Intel® VT-X with extended pages tables (EPT)	Yup
Intel® secure key	Yup
Intel® OS Guard	Yup
Intel® Software Guard Extensions (Intel® SGX)	Yup
Intel® 64	Yup
Technology Intel® Virtualization (VT-X)	Yup
Virtualization intellitecnology for direct I / O (VT-D)	Yup
Intel® Boot Guard	Yup
Persistent memory Intel® Optane ™ DC supported	No
Platform eligibility Intel® VPro ™	Yup
T-intersection	100 ° C
Supported memory types	Ddr4-SDRAM
Harmonized system code (SA)	85423119
Type of packaging	Box for retail
Size of the processor package	37.5 x 37.5 mm
Supported maximum RAM	128 GB
Launch date	T3'21
State	Launched
Maintenance status	Basic management
