Intel Core i7-12700. Processor family: Intel® Core ™ i7, Processor socket: LGA 1700, processor manufacturer: Intel. Memory channels: dual-channel, maximum internal memory supported by the processor: 128 GB, memory types supported by the processor: DDR4-SDRAM, DDR5-SDRAM. Integrated graphics card template: Intel UHD Graphics 770, outputs supported by the integrated graphics card adapter: Embedded DisplayPort (EDP) 1.4B, DisplayPort 1.4a, HDMI 2.1, Basic frequency of the integrated graphics card adapter: 300 MHz. Market segment: Desktop, Terms of Use: PC / Client / Tablet, Workstation, PCI Express Slot Version: 5.0, 4.0. Intel® Turbo Frequency Boost Max Technology 3.0: 4.9 GHz

Processor family	Intel® Core ™ i7
Processor core number	12
Processor socket	LGA 1700
Box	Yup
Cooler included	Yup
Processor manufacturer	Intel
Processor model	i7-12700
Processor operating mode	64-bit
Processor generation	Intel12th generation ® Core ™ i7
Number of processor threads	20
Heart of performance	8
Efficient nuclei	4
Maximum frequency of the Turbo processor	4.9 GHz
Frequency of increase in core performance	4.8 GHz
Basic performance core frequency	2.1 GHz
Frequency of efficient core enhancement	3.6 GHz
Efficient core base frequency	1.6 GHz
Processor cache	25 MB
Type of processor cache	Smart cache
Basic processor power	65 W
Maximum turbo power	180 W
Type of bus	Dmi4
Maximum number of DMI lanes	8
Memory band supported by the processor (maximum)	76.8 GB / s
Processor code name	Lake Alder
ARK processor ID	134591
Memory channels	Dual-channel
Maximum internal memory supported by the processor	128 GB
Types of memory supported by the processor	DDR4-SDRAM, DDR5-SDRAM
Data integrity control	Yup
Memory bandwidth (maximum)	76.8 GB / s
Integrated graphics card	Yup
Separate graphics card adapter	No
Integrated graphics card template	Intel UHD Graphics 770
Dedicated graphics card	Unavailable
Outputs supported by the integrated graphics card adapter	Embedded DisplayPort (EDP) 1.4B, DisplayPort 1.4a, HDMI 2.1
Basic frequency of the integrated graphics card adapter	300 MHz
Integrated graphics card adapter dynamic frequency (maximum)	1500 MHz
Number of views (Integrated graphics card)	4
DirectX version of the integrated graphics card adapter	12.0
OpenGL version of the integrated graphics card adapter	4.5
Maximum resolution of the integrated graphics card adapter (DisplayPort)	7680 x 4320 pixels
Maximum resolution of the integrated graphic adapter (EDP - integrated flat panel)	5120 x 3200 pixels
Maximum resolution of the integrated graphics card adapter (HDMI)	4096 x 2160 pixels
Refreshment frequency of the integrated graphic adapter at maximum resolution (DisplayPort)	60 Hz
Refreshment frequency of the integrated graphic adapter at maximum resolution (EDP - integrated flat panel)	120 Hz
Refreshment frequency of the graphic adapter integrated at maximum resolution (HDMI)	60 Hz
Installed graphics card adapter ID	0x4680
Number of operating units	32
Multi-format codec motors	2
Execution disabling bits	Yup
Inactive states	Yup
Thermal monitoring technology	Yup
Market segment	Desk
Terms of use	PC / client / tablet, workstation
Maximum number of PCI Express lanes	20
PCI Express slot version	5.0, 4.0
pCI Express configuration	1x16 + 1x4, 2x8 + 1x4
Supported instructions	SSE4.1, SSE4.2, AVX 2.0
Scalability	1s
CPU configuration (max)	1
Built-in options available	No
DMI review (Direct Media Interface)	4.0
Classification number of export control (eccn)	5a992cn3
Automatic tracking system of the goods classification (CCATS)	G167599
Intelil text is not provided. Please provide the text you want to translate. Hyper Threading technology)Intel® HT technology	Yup
Technology Intel® Turbo Boost	2.0
Quick Sync Video Inteltecnology Technology	Yup
Ligal HD video intelleclanology (Intel® CVT HD)	Yup
Intel® New Instructions AESINTEL® AES-NI	Yup
Enhanced technology Intel Speedstep	Yup
Reliable intelet technology	Yup
Technology Intel® speed change	Yup
Intel® Frequency of Turbo Boost Max 3.0 technology	4.9 GHz
Intel® Total memory encryption	Yup
Intel® Gaussian accelerator and NeuralIntel® GNA) 3.0	Yup
Inteltecnology of execution flow control (CET)	Yup
Intel Thread manager	Yup
Intel® VT-X with extended pages tables (EPT)	Yup
Intel® secure key	Yup
Active intelestion technology (Intel® AMT)	Yup
Intel® Stable image platform program (SIPP)	Yup
Intel® OS Guard	Yup
Intel® 64	Yup
Technology Intel® Virtualization (VT-X)	Yup
Virtualization intellitecnology for direct I / O (VT-D)	Yup
Technology Intel Turbo Boost max 3.0	Yup
Technology Intel Optane ready	Yup
Intel® Boot Guard	Yup
Intel® Deep Learning Boost (Intel® DL Boost) on the CPU	Yup
Axil volume management (VMD)	Yup
Running control based on modes (MBE)	Yup
Platform eligibility Intel® VPro ™	Yup
Technology Intel® Standard manageability (ISM)	Yup
Intel® Recovery with one click	Yup
Intelvirgualization technology with redirection protection (VT-RP)	Yup
Suitability of the corporate platform Intel vpro®	Yup
Threat detection technology Intel® (TDT)	Yup
Fitness Intel® Hardware shield	Yup
Technology Intel® Total memory encryption - Multi key	Yup
Suitability of the platform Intel vPRO® Essentials	Yup
T-intersection	100 ° C
OpenLC version	2.1
Harmonized system code (SA)	85423119
Type of packaging	Box for retail
Size of the processor package	45 x 37.5 mm
Supported maximum RAM	128 GB
Reference market	Gaming, content creation
Launch date	T1'22
State	Launched
Graphic output	eDP 1.4B, DP 1.4a, HDMI 2.1
