Intel® Gaussian and neural acceleratorIntel® Gaussian & Neural Accelerator (GNA) is a very low power accelerator block designed to perform workloads of artificial intelligence audio and focusing on speed. Intel® GNA is designed to perform neural networks based on extremely low power audio, allowing the CPU from this workload at the same time.
Intel® Deep Learning Boost (Intel® DL Boost)A new set of integrated processor technologies designed to accelerate cases of use in the Deep Learning of artificial intelligence. It extends Intel AVX-512 With the addition of a new education Vector Neural Network Instruction (Vnni) that significantly increases the performance of the inference for Deep Learning with respect to previous generations.
Intel® Deep Learning Boost (Intel® DL Boost)A new set of integrated processor technologies designed to accelerate cases of use in the Deep Learning of artificial intelligence. It extends Intel AVX-512 With the addition of a new education Vector Neural Network Instruction (Vnni) that significantly increases the performance of the inference for Deep Learning with respect to previous generations.
Memory Intel® Optane ™ supported ‡Memory Intel® Optane ™ is a new revolutionary non-volatile memory category that resides between the memory of the system and storage to accelerate the performance and response times of the system. When combined with the technology driver Intel® Rapid Storage, directly manages different storage levels by presenting a single virtual unit to the operating system and ensures that the most used data are in the fastest storage level. Memory Intel® Optane ™ requires a specific hardware and software configuration.
Technology Intel® speed changeTechnology Intel® Speed Shift uses the P States controlled by the hardware to offer significantly faster response times with mono-thread and transient workloads (short-lived), such as web browsing, allowing the processor to select voltage and frequencies to the processor more quickly to which best works to provide optimal levels of energy performance and efficiency.
Technology Intel® Turbo Boost ‡Technology Intel® Turbo Boost dynamically increases the frequency of the processor when necessary, taking advantage of the additional temperature and feed capacity to provide accelerations and reduce energy consumption when needed.
Technology Intel® Turbo Boost max 3.0Technology Intel® Turbo Boost max 3.0 Identifies the core with the best performance on the processor and provides them superior performance by increasing the frequency when requested, taking advantage of the power and the thermal margin.
Intelil text technology is not supplied. Please provide the text you want to translate. Hyper-InfoltimentoThe intelil text is not provided. Please provide the text you want to translate. Hyper-The threading technology provides two processing threads for each physical core. Applications with a high number of threads can perform multiple operations in parallel, completing activities in less time.
Intel® VT-X with extended pages tables (EPT)Intel® VT-X with extended page tables (EPT), also known as translation of second-level addresses (SLAT), provides acceleration for virtualized applications that require intensive use of memory. Extended page tables in the platforms with the intly virtualization technology reduces energy consumption, general memory costs and increases battery life through the hardware optimization of page tables management.
Intel® 64The architecture Intel® 64 makes 64-bit processing available on server, workstation, desktop and mobile platforms if combined with support supporto¹. The architecture Intel 64 offers an increase in performance thanks to the possibility for systems to use over 4 GB of virtual and physical memory.
Instruction setFor instruction set you mean the basic set of commands and instructions that a microprocessor is able to recognize and perform. The indicated value represents the instruction set of Intel with which the processor is compatible.
Inactivity statesInactivity states (states c) are used to reduce energy consumption when the processor is idle. C0 is the operating status and indicates that the CPU is performing useful operations. C1 is the first state of inactivity, C2 the second and so on. More actions are undertaken to reduce energy consumption, the number of states C.
Intel® New AES instructionsIntel® New Instructions Aesintel® AES-NI) are a set of instructions for fast encryption and data decryption. These instructions are valid for a wide range of encryption applications, for example: applications that perform mass encryption / decryption, authentication, random number generation and authenticated encryption.
Safety keyIntel® Secure Key consists of a digital generator of random numbers that creates random numbers to strengthen encryption algorithms.
Execution disabling bitsExecute Disable Bit is a hardware-based security feature designed to reduce exposure to viruses and malicious code attacks and preventing the performance and dissemination of dangerous software on the server or on the network.
Intel® Boot GuardThe intellecting device protection technology with boot guard helps protect the system's pre-know environment from harmful virus and software attacks.
Intel Core i5-12600K. Processor family: Intel® Core ™ i5, processor socket: LGA 1700, processor manufacturer: Intel. Memory channels: dual-channel, maximum internal memory supported by the processor: 128 GB, memory types supported by the processor: DDR4-SDRAM, DDR5-SDRAM. Integrated graphics card template: Intel UHD Graphics 770, outputs supported by the integrated graphics card: HDMI 2.1, DisplayPort 1.4a, built-in DisplayPort (EDP) 1.4B, Basic frequency of the integrated graphics card: 300 MHz. Market segment: Desktop, Terms of Use: PC / Client / Tablet, version of PCI Express slots: 5.0., , 4.0. Type of package: box for retail
Processor family | Intel® Core ™ i5 |
Processor core number | 10 |
Processor socket | LGA 1700 |
Box | Yup |
Cooler included | No |
Processor manufacturer | Intel |
Processor model | i5-12600k |
Processor operating mode | 64-bit |
Processor generation | Intel12th generation ® Core ™ i5 |
Component for | PC |
Number of processor threads | 16 |
Heart of performance | 6 |
Efficient nuclei | 4 |
Maximum frequency of the Turbo processor | 4.9 GHz |
Frequency of increase in core performance | 4.9 GHz |
Basic performance core frequency | 3.7 GHz |
Frequency of efficient core enhancement | 3.6 GHz |
Efficient core base frequency | 2.8 GHz |
Processor cache | 20 MB |
Type of processor cache | Smart cache |
Basic processor power | 125 W |
Maximum turbo power | 150 W |
Type of bus | Dmi4 |
Maximum number of DMI lanes | 8 |
Memory band supported by the processor (maximum) | 76.8 GB / s |
Processor code name | Lake Alder |
ARK processor ID | 134589 |
Memory channels | Dual-channel |
Maximum internal memory supported by the processor | 128 GB |
Types of memory supported by the processor | DDR4-SDRAM, DDR5-SDRAM |
Data integrity control | Yup |
Non-etc | Yup |
Memory bandwidth (maximum) | 76.8 GB / s |
Integrated graphics card | Yup |
Separate graphics card adapter | No |
Integrated graphics card template | Intel UHD Graphics 770 |
Dedicated graphics card | Unavailable |
Outputs supported by the integrated graphics card adapter | HDMI 2.1, DisplayPort 1.4a, Built-in DisplayPort (EDP) 1.4b |
Basic frequency of the integrated graphics card adapter | 300 MHz |
Integrated graphics card adapter dynamic frequency (maximum) | 1450 MHz |
Number of views (Integrated graphics card) | 4 |
DirectX version of the integrated graphics card adapter | 12.0 |
OpenGL version of the integrated graphics card adapter | 4.5 |
Maximum resolution of the integrated graphics card adapter (DisplayPort) | 7680 x 4320 pixels |
Maximum resolution of the integrated graphic adapter (EDP - integrated flat panel) | 5120 x 3200 pixels |
Maximum resolution of the integrated graphics card adapter (HDMI) | 4096 x 2160 pixels |
Refreshment frequency of the integrated graphic adapter at maximum resolution (DisplayPort) | 60 Hz |
Refreshment frequency of the integrated graphic adapter at maximum resolution (EDP - integrated flat panel) | 120 Hz |
Refreshment frequency of the graphic adapter integrated at maximum resolution (HDMI) | 60 Hz |
Installed graphics card adapter ID | 0x4680 |
Number of operating units | 32 |
Execution disabling bits | Yup |
Inactive states | Yup |
Thermal monitoring technology | Yup |
Market segment | Desk |
Terms of use | PC / client / tablet |
Maximum number of PCI Express lanes | 20 |
PCI Express slot version | 5.0, 4.0 |
pCI Express configuration | 1x16 + 1x4, 2x8 + 1x4 |
Supported instructions | SSE4.1, SSE4.2, AVX 2.0 |
Scalability | 1s |
CPU configuration (max) | 1 |
Built-in options available | No |
Description of the thermal solution | PCG 2020A |
Classification number of export control (eccn) | 5a992cn3 |
Automatic tracking system of the goods classification (CCATS) | G167599 |
Intelil text is not provided. Please provide the text you want to translate. Hyper Threading technology)Intel® HT technology | Yup |
Technology Intel® Turbo Boost | 2.0 |
Quick Sync Video Inteltecnology Technology | Yup |
Ligal HD video intelleclanology (Intel® CVT HD) | Yup |
Intel® New Instructions AESINTEL® AES-NI | Yup |
Enhanced technology Intel Speedstep | Yup |
Reliable intelet technology | Yup |
Technology Intel® speed change | Yup |
Intel® Total memory encryption | Yup |
Inteltecnology of execution flow control (CET) | Yup |
Intel Thread manager | Yup |
Intel® VT-X with extended pages tables (EPT) | Yup |
Intel® secure key | Yup |
Active intelestion technology (Intel® AMT) | Yup |
Intel® Stable image platform program (SIPP) | Yup |
Intel® OS Guard | Yup |
Intel® 64 | Yup |
Technology Intel® Virtualization (VT-X) | Yup |
Virtualization intellitecnology for direct I / O (VT-D) | Yup |
Technology Intel Turbo Boost max 3.0 | No |
Technology Intel Optane ready | Yup |
Intel® Boot Guard | Yup |
Intel® Deep Learning Boost (Intel® DL Boost) on the CPU | Yup |
Axil volume management (VMD) | Yup |
Running control based on modes (MBE) | Yup |
Platform eligibility Intel® VPro ™ | Yup |
Technology Intel® Standard manageability (ISM) | Yup |
Intel® Recovery with one click | Yup |
Intelvirgualization technology with redirection protection (VT-RP) | Yup |
Suitability of the corporate platform Intel vpro® | Yup |
Threat detection technology Intel® (TDT) | Yup |
Fitness Intel® Hardware shield | Yup |
Technology Intel® Total memory encryption - Multi key | Yup |
T-intersection | 100 ° C |
OpenLC version | 2.1 |
Harmonized system code (SA) | 85423119 |
Type of packaging | Box for retail |
Size of the processor package | 45 x 37.5 mm |
Supported maximum RAM | 128 GB |
Reference market | Games |
Launch date | T4'21 |
State | Launched |
Graphic output | eDP 1.4B, DP 1.4a, HDMI 2.1 |
