Intel Core i9-14900K. Family of the processor: Intel® CoreTM i9, Processor socket: LGA 1700, Processor Manufacturer: Intel. Memory channels: Dual-channel, Maximum internal memory supported by the processor: 192 GB, Memory types supported by the processor: DDR4-SDRAM, DDR5-SDRAM. Integrated graphics card model: Intel UHD Graphics 770, outputs supported by the integrated graphics card adapter: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1, Built-in Graphic Card Adapter Basic Frequency: 300 MHz. Market segment: Desktop, Terms of Use: Work station, PC/Client/Tablet, PCI Express slot version: 4.0, 5.0. Intel® Frequency Turbo Boost Max Technology 3.0: 5,8 GHz, Intel® Thermal speed increase frequency: 6 GHz

Family of the processor	Intel® CoreTM i9
Number of cores of the processor	24
Taken for processor	LGA 1700
Box	Yes
Cooler included	No
Processor Manufacturer	Intel
Processor Model	i9-14900K
Processor operating mode	64-bit
Generation of the processor	Intel Core i9-14xxx
Number of processor threads	32
Heart of performance	8
Efficient cores	16
Maximum frequency of the turbo processor	6 GHz
Performance core enhancement frequency	5.6 GHz
Basic performance core frequency	3,2 GHz
Efficient Core Increase Frequency	4,4 GHz
Efficient Core Basic Frequency	2,4 GHz
Processor Cache	36 MB
Processor cache type	Smart cables
Basic power of the processor	125 W
Maximum turbo power	253 W
Passage	B
Maximum number of DMI lanes	8
Memory Band supported by the processor (max)	89.6 GB/s
Processor code name	Lake Raptor
Processor ID ARK	236773
Memory channels	Double channel
Maximum internal memory supported by the processor	192 GB
Memory types supported by the processor	DDR4-SDRAM, DDR5-SDRAM
Verification of Data Integrity	Yes
Non-ECC	Yes
Width of memory band (maximum)	89.6 GB/s
Integrated graphics card	Yes
Separate graphics card adapter	No
Integrated Graphic Card Model	Intel UHD Graphics 770
Dedicated graphics card	Not available
Outputs supported by the integrated graphics card adapter	Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
Integrated Graphic Card Adapter Basic Frequency	300 MHz
Dynamic frequency of integrated graphics card adapter (max)	1650 MHz
Number of views (integrated graphics card)	4
DirectX version of integrated graphics card adapter	12.0
OpenGL version of integrated graphics card adapter	4.5
Maximum resolution of integrated graphics card adapter (Displayport)	7680 x 4320 Pixel
Maximum resolution of the integrated graphic adapter (eDP - Integrated Plate Panel)	5120 x 3200 Pixel
Maximum resolution of integrated graphics card adapter (HDMI)	4096 x 2160 Pixel
Updating frequency of the integrated graphic adapter at maximum resolution (DisplayPort)	60 Hz
Updating frequency of the integrated graphic adapter at maximum resolution (eDP - Integrated Plate Panel)	120 Hz
Updating frequency of the integrated graphic adapter at maximum resolution (HDMI)	60 Hz
Installed Graphic Card Adapter ID	0xA780 Other
Number of operating units	32
Multiformed codec engines	2
Execution disabling bit	Yes
Inactive	Yes
Thermal Monitoring Technology	Yes
Market segment	Desk
Terms of use	Working station, PC/Client/Tablet
Maximum number of Express PCI lanes	20
Version of PCI Express slots	4.0, 5.0
pCI Express configuration	1x16+1x4, 2x8+1x4
Supported instructions	AVX 2.0, SSE4.1, SSE4.2
Scalability	1
CPU configuration (max)	1
Built-in options available	No
Description of thermal solution	PCG 2020A
(Direct Media Interface)	4.0
Number of export control classifications (ECCN)	5A992C
Automatic tracking system of the classification of goods (CCATS)	740.17B1
Can Intel provide the text I have to translate? Hyper Threading Technology)Intel® Technology	Yes
Technology Intel® Turbo Boost	2.0
Intel Technology Quick Sync Video	Yes
Intel® Technology Clear Video HDIntel® CVT HD)	Yes
Intel® New AES instructions (Intel® AES-NI	Yes
Enhanced technology Intel SpeedStep	Yes
Technology Intel® Speed change	Yes
Increase Intel Thermal Speed Sorry, but you did not provide any text to translate.	Yes
Technology Intel® Boost Adactive	Yes
Intel® Turbo Boost Max 3.0 Technology Frequency	5.8 GHz
Intel® Gaussian and Neural Accelerator (Intel® GNA) 3.0	Yes
Intel® Frequency Boost Thermal Speed	6 GHz
Intel® Execution Flow Control Technology (CET)	Yes
Intel Director of the Wire	Yes
Intel® VT-x with extended pages tables (EPT)	Yes
Intel® Safe Key	Yes
Intel® OS Guard	Yes
Intel® 64	Yes
Technology Intel® Virtualization (VT-x)	Yes
IntelVirtualization Technology for Direct I/O (VT-d)	Yes
Technology Intel Turbo Boost Max 3.0	Yes
IntelBoot Guard	Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU	Yes
Intel® Volume Management Device (VMD)	Yes
Mode-based execution control (MBE)	Yes
Technology Intel® Standard Manageability (ISM)	Yes
T-section	100 °C
OpenLC version	3.0
Harmonized System Code (SA)	8542310001
Dimensions of the processor packaging	45 x 37,5 mm
Cache L2	32768 KB
Maximum supported RAM	192 GB
Launch date	Q4.23
State	Launched
Graphic output	eDP 1.4b, DP 1.4a, HDMI 2.1
