Intel Core i7-14700K. Processor family: Intel® Core™ i7, Processor socket: LGA 1700, Processor manufacturer: Intel. Memory channels: Dual-channel, Maximum internal memory supported by the processor: 192 GB, Types of memory supported by the processor: DDR4-SDRAM, DDR5-SDRAM. Integrated graphics card model: Intel UHD Graphics 770, Supported outputs of the integrated graphics card: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1, Base frequency of the integrated graphics card: 300 MHz. Market segment: Desktop, Usage conditions: Workstation, PC/Client/Tablet, Version of PCI Express slots: 4.0, 5.0. Intel® Turbo Boost Max Technology 3.0 frequency: 5.6 GHz

Processor family	Intel® Core™ i7
Number of processor cores	20
Taken for processor	LGA 1700
Box	Yes
Cooler included	No
Processor manufacturer	Intel
Processor model	i7-14700K
Processor operating mode	64-bit
Processor generation	Intel Core i7-14xxx
Number of processor threads	28
Heart of performance	8
Efficient cores	12
Maximum turbo processor frequency	5.6 GHz
Frequency of core performance increase	5.5 GHz
Base frequency of the performance core	3.4 GHz
Efficient core boost frequency	4.3 GHz
Base frequency of the efficient core	2.5 GHz
Processor cache	33 MB
Processor cache type	Smart Cache
Base power of the processor	125 W
Maximum turbo power	253 W
Step	B0
Maximum number of DMI lanes	8
Supported memory band by the processor (max)	89.6 GB/s
Processor code name	Raptor Lake
ARK Processor ID	236783
Memory channels	Dual-channel
Maximum internal memory supported by the processor	192 GB
Types of memory supported by the processor	DDR4-SDRAM, DDR5-SDRAM
Data Integrity Check	Yes
Non-ECC	Yes
Memory bandwidth (maximum)	89.6 GB/s
Integrated graphics card	Yes
Separate graphics card adapter	No
Integrated graphics card model	Intel UHD Graphics 770
Dedicated graphics card	Not available
Supported outputs of the integrated graphics card adapter	Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
Base frequency of the integrated graphics card adapter	300 MHz
Dynamic frequency of the integrated graphics card adapter (max)	1600 MHz
Number of views (integrated graphics card)	4
DirectX version of the integrated graphics card adapter	12.0
OpenGL version of the integrated graphics card adapter	4.5
Maximum resolution of the integrated graphics card adapter (Displayport)	7680 x 4320 Pixels
Maximum resolution of the integrated graphics adapter (eDP - Integrated flat panel)	5120 x 3200 Pixels
Maximum resolution of the integrated graphics card adapter (HDMI)	4096 x 2160 Pixels
Refresh rate of the integrated graphics adapter at maximum resolution (DisplayPort)	60 Hz
Refresh rate of the integrated graphics adapter at maximum resolution (eDP - Integrated Flat Panel)	120 Hz
Refresh rate of the integrated graphics adapter at maximum resolution (HDMI)	60 Hz
ID of the installed graphics card adapter	The text you provided is not in Italian. It appears to be a hexadecimal code. Please provide a valid Italian text to translate it into English.
Number of operational units	32
Multiformat codec engines	2
Execution disable bit	Yes
Inactive states	Yes
Thermal Monitoring Technology	Yes
Market segment	Desk
Terms of use	Workstation, PC/Client/Tablet
Maximum number of PCI Express lanes	20
Version of PCI Express slots	4.0, 5.0
PCI Express configuration	1x16+1x4, 2x8+1x4 translates to: 1 times 16 plus 1 times 4, 2 times 8 plus 1 times 4
Supported instructions	AVX 2.0, SSE4.1, SSE4.2
Scalability	1S
CPU configuration (max)	1
Built-in options available	No
Description of the thermal solution	PCG 2020A
DMI (Direct Media Interface) Review	4.0
Export Control Classification Number (ECCN)	5A992C
Automatic Commodity Classification Tracking System (CCATS)	740.17B1
The text you provided is a symbol, not Italian text. Please provide a valid Italian text to translate it into English. Hyper Threading technologyIntel® HT Technology	Yes
Technology Intel® Turbo Boost	2.0
Intel Quick Sync Video Technology	Yes
Intel Clear Video HD Technology ®Intel® CVT HD)	Yes
Intel® New AES InstructionsIntel® AES-NI	Yes
Enhanced technology Intel SpeedStep	Yes
Technology Intel® Speed Shift	Yes
Intel® Turbo Boost Max Technology 3.0 Frequency	5.6 GHz
IntelGaussian & Neural AcceleratorIntelYour text does not appear to be in Spanish. Can you try again?	Yes
Intel Control-flow Enforcement Technology (CET)	Yes
Intel Director of the Wire	Yes
Intel® VT-x with extended page tables (EPT)	Yes
Intel® Security Key	Yes
Intel® OS Guard	Yes
Intel® 64	Yes
Technology Intel® Virtualization (VT-x)	Yes
Intel Virtualization Technology for Direct I/O (VT-d)	Yes
Technology Intel Turbo Boost Max 3.0	Yes
IntelBoot Guard	Yes
Intel® Deep Learning BoostIntel® DL Boost) on CPU	Yes
Intel Volume Management Device (VMD)	Yes
Mode-Based Execution Control (MBE)	Yes
Technology Intel® Standard Management (ISM)	Yes
T intersection	100 °C
OpenLC Version	3.0
Harmonized System Code (HS)	8542310001
Processor package dimensions	45 x 37.5 mm
L2 Cache	28672 KB
Maximum RAM supported	192 GB
Launch date	Q4'23
State	Launched
Graphic output	eDP 1.4b, DP 1.4a, HDMI 2.1
