With a brightness of 3,500 lumens and HD-readyWXGA resolution, the EB-695Wi's ultra-short-throw design allows you to present large images from a very short distance with minimised shadows and glare. This projector offers ultimate interactivity by combining finger-touch with dual pen capability. A 14,000:1 contrast ratio and HDMI input mean that students benefit from sharp, clear images.

High brightness and image quality
Epson’s 3LCD technology ensures high-quality images with equally high White and Colour Light Output for vivid colours and bright images, even in daylight, and three times brighter colours than leading competitive projectors1. With a scalable display size of up to 100 inches, two types of content can be displayed using the split-screen without compromising on quality.

Finger-touch and dual pen
Use your fingers to annotate directly onto the screen. Epson's interactive pens are now even more responsive and easy to use. With the new dual pens, teacher and student or two students can work simultaneously using different attributes.

Highly reliable
Project for longer with improved reliability and a longer lamp life of up to 10,000 hours in eco mode.

Interact and enhance learning
Multi-PC projection software allows teachers and students to share content simultaneously. The moderator function allows teachers to remain in control, choosing what content to display. Combine two projectors to create one large interactive display. Split-screen capability allows teachers to display two separate types of content simultaneously, such as a lesson plan from a PC and a still image or video clip from a document camera.

Optional wireless capability
Wirelessly display content easily from a range of smart devices and Google Chromebooks using our iProjection App.

Epson EB-695Wi. Projector brightness: 3500 ANSI lumens, Projection technology: 3LCD, Projector native resolution: WXGA (1280x800). Light source type: Lamp, Service life of light source: 5000 h, Service life of light source (economic mode): 10000 h. Focus: Manual, Focal length range: 3.7 mm, Fixed focal length: 0.146" (3.7 mm). Video processing: 10 bit, Color modes (2D): Cinema, Dynamic, Video color modes: Blackboard, Cinema, Dynamic, Presentation, sRGB. Serial interface type: RS-232C

Projector brightness	3500 ANSI lumens
Projection technology	3LCD
Projector native resolution	WXGA (1280x800)
Contrast ratio (typical)	14000:1
Native aspect ratio	16:10
Screen size compatibility	60 - 100"
Supported aspect ratios	16:10
Projection distance (wide)	0 - 15.7" (0 - 0.4 m)
Projection distance (tele)	0 - 23.6" (0 - 0.6 m)
Contrast ratio (dynamic)	14000:1
Number of colors	1.07 billion colors
Projector brightness (economic mode)	2900 ANSI lumens
Vertical scan range	100 - 120 Hz
Keystone correction, horizontal	-3 - 3°
Keystone correction, vertical	-3 - 3°
Matrix size	0.59"
Vertical synchronization (min)	0.1 kHz
Vertical synchronization (max)	0.12 kHz
White light output	3500 ANSI lumens
Color light output	3500 ANSI lumens
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
Lamp power	250 W
Focus	Manual
Focal length range	3.7 mm
Fixed focal length	0.146" (3.7 mm)
Aperture range (F-F)	0 - 1.6
Zoom type	Auto
Zoom ratio	1.35:1
Digital zoom	1.35x
Throw ratio	0.28 - 0.37:1
Full HD	No
3D	No
Video processing	10 bit
Color modes (2D)	Cinema, Dynamic
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
VGA (D-Sub) ports quantity	3
HDMI ports quantity	3
Composite video in	1
Component video (YPbPr/YCbCr) in	0
DVI port	No
Audio (L/R) in	1
Serial interface type	RS-232C
S-Video inputs quantity	1
USB 2.0 ports quantity	1
USB 2.0 Type-B ports quantity	1
Headphone outputs	1
Microphone in	Yes
Mobile High-Definition Link (MHL)	Yes
AC (power) in	Yes
Consumer Electronics Control (CEC) support	Yes
Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	1
Ethernet LAN data rates	10,100 Mbit/s
Card reader integrated	No
Noise level	35 dB
Interactive	Yes
Interactive input supported	Interactive pen/Touch
Noise level (economic mode)	30 dB
On Screen Display (OSD)	Yes
Country of origin	Philippines
Password protection	Yes
Compatible operating systems	Linux, Mac OS 10.10.x, Mac OS 10.7.x, Mac OS 10.8.x, Mac OS 10.9.x, Ubuntu 14.10, Ubuntu 15.04, Ubuntu 15.10, Ubuntu 16.04 LTS, Windows 10, Windows 8, Windows 8.1
Certification	TCO
Built-in speaker(s)	Yes
RMS rated power	16 W
Product type	Ultra short throw projector
Market positioning	Ultra short throw
Product color	White, Gray
Placement	Wall
LED indicators	Yes
Cable lock slot	Yes
Cable lock slot type	Kensington
Built-in display	No
Power source	AC
Power consumption (typical)	354 W
Power consumption (standby)	0.37 W
Power consumption (economy mode)	309 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Software support	via: AMX, Crestron (Network), Control4
Windows operating systems supported	Windows 10, Windows 8, Windows 8.1
Mac compatibility	Yes
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Linux operating systems supported	Yes
Operating temperature (T-T)	5 - 40 °C
Storage temperature (T-T)	-10 - 60 °C
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	10 - 90%
Weight	12.8 lbs (5.8 kg)
Width	14.4" (367 mm)
Depth	15.7" (400 mm)
Height	5.87" (149 mm)
Package width	19.3" (490 mm)
Package depth	29.1" (740 mm)
Package height	13.2" (335 mm)
Package weight	47.6 lbs (21.6 kg)
Handheld remote control	Yes
Batteries included	Yes
Cables included	AC
Quick start guide	Yes
Manual	Yes
Mounting brackets included	Yes
Warranty card	Yes
WLAN adapter included	Yes
Bundled software	Easy Interactive Tools, EasyMP Multi PC Projection, Epson Projektor Management
Sustainability certificates	TCO
Quantity per pack	1 pc(s)
Quantity per pallet	12 pc(s)
Pallet weight	0 oz (0 g)
Pallet length	47.2" (120 cm)
Pallet width	31.5" (80 cm)
Pallet height	5.91" (15 cm)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	2 pc(s)
Quantity per pallet (UK)	12 pc(s)
Pallet weight (UK)	0 oz (0 g)
Pallet length (UK)	47.2" (120 cm)
Pallet width (UK)	39.4" (100 cm)
Pallet height (UK)	5.91" (15 cm)
Harmonized System (HS) code	85286200
RS-232 ports	1
RS-232C	Yes
USB display function	3 in 1: Image / Mouse / Sound
