Total power | 650 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Maximum input current (@ 110V) | 10 |
Maximum input current (@ 220V) | 5 a |
Power factor corrector type (PFC) | Active |
Combined power (+ 3.3V) | 110 W |
Combined power (+ 12V) | 648 W |
Combined power (+ 5V) | 110 W |
Combined power (-12V) | 3.6 W |
Combined power (+ 5VSB) | 12.5 W |
Maximum output current (+ 3.3V) | 20 A |
Maximum output current (+ 12V) | 54 a |
Maximum output current (+ 5V) | 20 A |
Maximum output current (-12V) | 0.3 a |
Maximum output current (+ 5VSB) | 20 A |
Efficiency | 85% |
Power protection capabilities | Overcurrent, supercharging, overload, short circuit |
Motherboard connector | 20 + 4 pin ATX |
Peripheral connectors (Molex) (4-pin) | 2 |
Motherboard power cable length | 60 cm |
Number of SATA connectors | 5 |
EPS power connector (8-pin) | No |
EPS power connector (4 + 4 poles) | Yup |
PCI Express connectors (6 + 2 Pins) | 2 |
CPU power connector (4 + 4-pin) | Yup |
ATX connector (24-pin) | No |
ATX connector (20 + 4-pin) | Yup |
Floppy Disc connector | No |
Type of wiring | Not modular |
Use | PC |
Power unit shape factor (PSU) | ATX |
80 Plus certification | 80 plus bronze |
Product color | Black |
Type of cooling | Active |
Fan diameter | 12 cm |
Fan number | 1 fan (s) |
Interruper on / off | Yup |
Width | 150 mm |
Depth | 140 mm |
Height | 86 mm |
Harmonized system code (SA) | 84733020 |
