Faster, smarter WiFi for everyone
The new WiFi 6 standard delivers faster, more consistent connections for every user – even in higher density environments. Any organization that needs to accommodate a large number of devices, can offer better services for everyone, every time they connect to WiFi.

Better-connected classrooms for immersive learning
By delivering faster connections that won’t suffer from increased latency when more devices are connected, WiFi 6 delivers the speed and consistency needed to keep pupils engaged and enthusiastic, so they can make the very best use of technology and online learning resources, helping them to achieve more and teachers to be more effective.

A smarter solution
The WAX650S is also equipped with Zyxel Smart Antenna that continually monitors and adapts every connection to every device, ensuring the optimum performance is delivered at all times. It prevents the connection inconsistencies and delays caused by interferences.

Robust hardware design you can trust
Every hardware design detail is critical to performance and reliability. The WAX650S access point is built with selected high quality components to warrant the best experience and longevity.

Manage it your way!
As it comes with support for NebulaFlex Pro, Zyxel’s scalable, cloud-based management system, the WAX650S can be managed via NCC (Nebula control Center), on-premises controller or simply operate alone (controller less). You can choose the way that is best suited to your needs.

Zyxel WAX650S. 2.4 GHz, 5 GHz, Maximum data transfer rate: 3550 Mbit/s. Security algorithms: SNMP, WEP, WPA-Enterprise, WPA-PSK, WPA2, WPA3. Ethernet LAN data rates: 1000,2500,5000 Mbit/s. Power over Ethernet (PoE). Product color: White

2.4 GHz	Yes
5 GHz	Yes
Maximum data transfer rate	3550 Mbit/s
Maximum data transfer rate (2.4 GHz)	1150 Mbit/s
Maximum data transfer rate (5 GHz)	2400 Mbit/s
Ethernet LAN data rates	1000,2500,5000 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3bt
MIMO	Yes
MIMO type	Multi User MIMO
Wi-Fi Multimedia (WMM)/(WME)	Yes
Fast roaming	Yes
VLAN support	Yes
Wireless isolation	Yes
Band steering	Yes
Transmitting power	26 dBmW
Receiver sensitivity	-105 dBm
Security algorithms	SNMP, WEP, WPA-Enterprise, WPA-PSK, WPA2, WPA3
MAC address filtering	Yes
Auto Wireless Distribution System (WDS)	Yes
Web-based management	Yes
Firmware upgradeable	Yes
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	0
DC-in jack	Yes
Power over Ethernet (PoE)	Yes
AC input voltage	12 V
Product color	White
Antenna type	Internal
Antenna gain level (max)	5.8 dBi
Certification	FCC 15C, FCC 15E, ETSI EN 300 328, EN 301 893, LP0002 FCC 15B, EN 301 489-1, EN 301 489-17, EN55022, EN55024, EN61000-3-2/-3, EN60601-1-2, BSMI CNS13438 EN 60950-1, IEC 60950-1, BSMI CNS14336-1
Width	9.06" (230 mm)
Depth	9.25" (235 mm)
Height	2.11" (53.5 mm)
Weight	2.56 lbs (1.16 kg)
Package width	11.1" (282 mm)
Package depth	10.5" (266 mm)
Package height	3.11" (79 mm)
Package weight	3.28 lbs (1.49 kg)
Quantity per pack	1 pc(s)
Mounting kit	Yes
Operating relative humidity (H-H)	10 - 95%
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-30 - 70 °C
Storage relative humidity (H-H)	10 - 90%
Harmonized System (HS) code	85176990
