The Intel Xeon® Silver 4208 2.1GHz Eight Core Processor enhances the performance and the speed of your system. Additionally, the Virtualization Technology enables migration of more environments. It supports enhanced SpeedStep® technology that allows tradeoffs to be made between performance and power consumption.

Its Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. The VT-x with Extended Page Tables (EPT) also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Packed with more features, the Xeon Silver 4208 2.1GHz Eight Core Processor is the ideal choice for virtually all of your data demanding or standard enterprise infrastructure applications.

This product is compatible with the following systems:

- PowerEdge R640
- PowerEdge R740
- PowerEdge R740XD
- PowerEdge C6420
- Precision Workstation 7820 Tower
- PowerEdge R440
- PowerEdge T640
- PowerEdge T440
- PowerEdge FC640
- PowerEdge M640
- PowerEdge M640 VRTX
- Precision Workstation R7920
- Precision Workstation 7920 Tower
- PowerEdge R540
- PowerEdge MX740c
- PowerEdge XR2

DELL Xeon Silver 4208. Processor family: Intel Xeon Silver, Processor socket: LGA 3647 (Socket P), Processor lithography: 14 nm. Memory channels: Hexa-channel, Maximum internal memory supported by processor: 1.02 TB, Memory types supported by processor: DDR4-SDRAM. Market segment: Server, Supported instruction sets: AVX-512, Scalability: 2S. Processor package size: 76.0 x 56.5 mm. Compatibility: - PowerEdge C6420 - PowerEdge FC640 - PowerEdge M640 - PowerEdge M640 VRTX - PowerEdge MX740C -...

Processor family	Intel Xeon Silver
Processor cores	8
Processor socket	LGA 3647 (Socket P)
Processor lithography	14 nm
Processor model	4208
Processor base frequency	2.1 GHz
Processor operating modes	64-bit
Processor generation	2nd Generation Intel® Xeon® Scalable
Component for	Server/workstation
Processor threads	16
Processor boost frequency	3.2 GHz
Processor cache	11 MB
Thermal Design Power (TDP)	85 W
Processor codename	Cascade Lake
Processor ARK ID	193390
Memory channels	Hexa-channel
Maximum internal memory supported by processor	1.02 TB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2400 MHz
ECC	Yes
On-board graphics card	No
Discrete graphics card	No
On-board graphics card model	Not available
Discrete graphics card model	Not available
Execute Disable Bit	Yes
Market segment	Server
Maximum number of PCI Express lanes	48
PCI Express slots version	3.0
Supported instruction sets	AVX-512
Scalability	2S
Embedded options available	No
PCI Express CEM revision	3.0
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Turbo Boost Technology	2.0
Intel® AES New Instructions (Intel® AES-NI)	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel Trusted Execution Technology	Yes
Intel® Speed Shift Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel TSX-NI	Yes
Intel 64	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel Turbo Boost Max Technology 3.0	No
AVX-512 Fused Multiply-Add (FMA) units	1
Intel® Deep Learning Boost (Intel® DL Boost) on CPU	Yes
Intel® Speed Select technology - Performance Profile (Intel® SST-PP)	No
Intel® Resource Director Technology (Intel® RDT)	Yes
Intel® Volume Management Device (VMD)	Yes
Intel® Run Sure Technology	No
Mode-based Execute Control (MBE)	Yes
Intel® Optane™ DC Persistent Memory Supported	No
Intel® vPro™ Platform Eligibility	Yes
Intel® Speed Select Technology - Base Frequency (Intel® SST-BF)	No
Tcase	78 °C
Product type	Processor
Harmonized System (HS) code	85423119
Processor package size	76.0 x 56.5 mm
Compatibility	- PowerEdge C6420 - PowerEdge FC640 - PowerEdge M640 - PowerEdge M640 VRTX - PowerEdge MX740C - PowerEdge R440 - PowerEdge R540 - PowerEdge R640 - PowerEdge R740 - PowerEdge R740XD - PowerEdge T440 - PowerEdge T640 - PowerEdge XR2
Intel Speed Select Technology (SST)	No
Intel® Optane™ DC Persistent Memory technology	No
Launch date	Q2'19
Status	Launched
Memory speed (max)	2400 MHz
Number of UPI links	2
